Tiny, magnetically controlled robots coax nerve cells to grow connections

New research could point to additional treatments for people with nerve injuries

nerve cells and a tiny robot

Nerve cells (colored blue and green in this microscope image) grow along thin grooves of a microrobot that scientists control with magnetic fields.

Hongsoo Choi/ DGIST-ETH Microrobotics Research Center

Tiny robots can operate as nerve cell connectors, bridging gaps between two distinct groups of cells. These microscopic patches may lead to more sophisticated ways to grow networks of nerve cells in the laboratory, and perhaps even illuminate ways to repair severed nerve cells in people, researchers report September 25 in Science Advances.

Engineers Eunhee Kim and Hongsoo Choi, both of the Daegu Gyeongbuk Institute of Science and Technology in South Korea, and colleagues first built rectangular robots that were 300 micrometers long. Slender horizontal grooves, about the width of nerve cells’ tendrils that exchange messages with other cells, lined the top.

These microrobots were fertile ground for rat nerve cells, the researchers found. As the cells grew, their message-sending axons and message-receiving dendrites neatly followed the robots’ lined grooves.

Once laden with about 100 nerve cells, a microrobot’s objective was to nestle between two separate islands of nerve cells, grown on glass plates, and bridge the gap. Rotating magnetic fields sent the microrobot tumbling pell-mell toward its target. When the microrobot drew close, researchers used a steadier magnetic field to align the bot between the two clusters of cells.

a tiny robot connecting nerve cell clusters
A microrobot carrying nerve cells (center bridge) connects two separate clusters of nerve cells (cell bodies are colored green in this micrograph, nuclei are blue), enabling those clusters to communicate.Eunhee Kim, Hongsoo Choi

The nerve cells on the microrobot then grew out toward the clusters, while the cells in the clusters grew onto the bot. These new connections allowed neural signals to flow from one cluster of nerve cells to another, electrodes revealed.

Creating these neural bridges might help researchers design better replicas of complex nerve cell networks in the brain. Similar systems could also lead to new ways of studying nerve cell growth, experiments that could ultimately point to therapies for people with nerve injuries (SN: 8/11/16). Such precision building could also be useful in computing, allowing scientists to design and build biological computers with nerve cells.

Laura Sanders is the neuroscience writer. She holds a Ph.D. in molecular biology from the University of Southern California.
