# Time-domain simulation of a guitar: model and method.

@article{Derveaux2003TimedomainSO, title={Time-domain simulation of a guitar: model and method.}, author={Gr{\'e}goire Derveaux and Antoine Chaigne and Patrick Joly and {\'E}liane B{\'e}cache}, journal={The Journal of the Acoustical Society of America}, year={2003}, volume={114 6 Pt 1}, pages={ 3368-83 } }

This paper presents a three-dimensional time-domain numerical model of the vibration and acoustic radiation from a guitar. The model involves the transverse displacement of the string excited by a force pulse, the flexural motion of the soundboard, and the sound radiation. A specific spectral method is used for solving the Kirchhoff-Love's dynamic top plate model for a damped, heterogeneous orthotropic material. The air-plate interaction is solved with a fictitious domain method, and a… Expand
